The model QRS31 3-Axis Control Quartz System is a compact, lightweight design, that features Quartz MEMS technology based on three solid-state gyros offering virtually unlimited life. The QRS31’s combination of high performance and long life makes it well suited for OEM’s and system integrators designing cost-effective, high-performance systems.
The QRS31 requires only DC voltage inputs to provide reliable, extremely accurate angular rate measurements with the benefit of no moving parts. With a hermetically sealed sensing element, the QRS31 has provided reliable performance in aircraft, missile and space systems across many demanding application environments.
System Performance
| PARAMETERS | SPECIFICATIONS |
|---|---|
| Standard Range | ± 150°/sec |
| Input Voltage | ± 15 ± 1 VDC |
| Output | ± 20 VDC Differential |
| Scale Factor | .133 V/°/sec (2) |
| G-Sensitivity | <± .02°/sec/g |
| Operating Temperature Range | -54 °C to +80 °C |
